Proof Without Words: Gregory’s Theorem

Archimedes famously used inscribed and circumscribed polygons to approximate the circumference of a circle. He then repeatedly doubled the numbers of sides to get an approximation for π.

James_GregoryIn 1667, James Gregory did the same, but he used areas: He discovered the following beautiful double-recurrence relation that can be used to compute the areas of inscribed and circumscribed n-gons:

Gregory’s Theorem. Let Ik and Ck denote the areas of regular k-gons inscribed in and circumscribed around a given circle. Then for all n, I2n is the geometric mean of In and Cn, and C2n is the harmonic mean of I2n and Cn; that is,

I_{2n}=\sqrt{I_{n}C_{n}} and C_{2n}=\frac{2}{\frac{1}{I_{2n}}+\frac{1}{C_{n}}}.

We can use these formulas to approximate π. For instance, a square inscribed in a unit circle has area I4=2 and a square circumscribed about the unit circle has area C4=4. Applying the recurrence relations, we obtain the following sequence of bounds:

n In Cn
4 2 4
8 2.828427125 3.313708499
16 3.061467459 3.182597878
32 3.121445152 3.151724907
64 3.136548491 3.144118385
128 3.140331157 3.14222363
256 3.141277251 3.141750369
512 3.141513801 3.141632081
1024 3.14157294 3.14160251
2048 3.141587725 3.141595118

This summer I tweeted this theorem:

My friend Tom Edgar—a mathematician at Pacific Lutheran University and a master at finding “proofs without words”—emailed me to see if I wanted to try finding a proof without words of Gregory’s theorem. This is what we came up with.

The two parts of Gregory’s theorem follow from the two parts of the following lemma. We give the proof… without words.

Lemma. \frac{I_{2n}}{I_n}=\frac{C_n}{I_{2n}} and \frac{C_n-C_{2n}}{C_{2n}-I_{2n}}=\frac{C_n}{I_{2n}}.

Proof.

main
